Fiber-Network Management
Map your network.Manage your connections.
CoreMap helps cable TV operators, broadband providers, LCOs, MSOs, and local ISPs replace paper maps with a precise digital view of routes, junction boxes, fiber cores, splices, couplers, and customer connections.
Start your 30-day free trial today
Your complete fiber network, mapped in one place.
Navigate through our professional modules designed specifically for network operations.
Fault Intelligence & Rapid Repair
Find faults faster. Restore service with context.
CoreMap helps teams identify the affected route, junction box, signal path, and customers quickly when a cable breakdown or signal drop occurs.
1. Coupler & Power Loss Diagnostics
Signal AlertMonitors stage-by-stage coupler power and optical dBm loss to identify fiber cuts instantly.
2. Affected Circuit & Customer Mapping
12 SubscribersMaps issue directly to JB-405-North and identifies 12 connected subscribers.
3. Precision Field Dispatch
Auto-DispatchedDispatches GPS pole location, tube color sequence, and spare core to technician.
Mobile Field Empowerment
Give field technicians the full network picture.
Technicians can review route details, junction-box profiles, fiber colors, splice paths, coupler information, and customer connections before beginning physical work.
Real-Time Cable & Port Mapping
Inspect input/output cable directions, tube configurations, and available capacity right at the junction box.
12-Color Core Verification
Standard visual color-code guide eliminates splicing errors and reversed fiber tubes.
Direct Subscriber Trace
Know exactly which subscriber connects to each coupler port without tracing manual wires.
Proactive Capacity Planning
Plan future connections with available capacity in view.
Identify available fiber cores, open ports, available coupler points, and suitable connection paths before planning new installations.
+40%
Faster Provisioning
Verify line readiness in seconds without field audits
0 Over-Splits
Optical Budget Safety
Maintain signal above -24 dBm across all branches
Proven Operational Advantages
Why cable and fiber operators choose CoreMap.
Built specifically to eliminate technician guesswork, lost paper maps, and unnecessary network downtime.
65% Faster MTTR
Faster troubleshooting
When a cable breakdown or signal-drop issue occurs, help identify the affected route, junction box, signal path, and customers more quickly.
Live Mobile Sync
Complete info for field staff
Give technicians access to fiber colors, connection paths, junction-box details, and customer relationships from a mobile-friendly network view.
Zero Knowledge Loss
Preserve network knowledge
Keep network information in the system instead of relying only on individual technician memory.
99.98% SLA Uptime
Reduce avoidable downtime
Find relevant network information faster so teams can investigate customer complaints and service issues more efficiently.
8 Spares Ready
Plan network expansion
Identify available fiber cores, open ports, and suitable connection paths before planning new installations.
Sub-Meter GIS
Replace paper maps & notebooks
Move from paper maps, diaries, handwritten records, and disconnected spreadsheets to one structured digital network system.
Tailored for Every Role
Built for local cable and fiber-network teams.
From network operators and NOC engineers to field technicians up on the ladder, CoreMap keeps everyone aligned.
Cable TV
Cable Operators
Map your cables, poles, and junction boxes in one place so your network history is never lost.
Complete network map
Track poles and boxes
Quick cable fault diagnosis
Safe history when staff leave
Broadband
Internet Providers
Check connection feasibility in seconds and track available ports before sending technicians.
Instant feasibility check
Live open port count
Clear route to each home
Verify signal before install
Engineering
Fiber Engineers
Design fiber routes, manage splitters, and calculate optical power loss automatically.
Visual fiber route layouts
Automatic power loss math
Clear box wire connections
Prevent weak customer signal
Field Crews
Field Technicians
Find poles on mobile GPS, view box connections, and follow standard fiber color codes on site.
12-fiber color code guide
GPS pole location finder
View box wires on mobile
Live updates to the office
Operator Experiences
Trusted by local cable TV operators & broadband providers.
See how local cable TV operators and broadband service providers eliminated messy paper diaries, resolved fiber breakdowns in minutes, and streamlined daily operations with CoreMap.
MS
Suneer
Multistar
5.0
“We run both Cable TV and Gigabit Broadband on shared 24-core trunks. Keeping track of color coding and core allocations was a daily headache. CoreMap gives us a crystal-clear core matrix for every tube and junction box. Complete peace of mind.”
Unified Core Allocation
SB
Binoy
Satvision Cable
4.9
“Earlier, when a main fiber line was cut, our team spent 3 to 4 hours checking every single joint along the road. With CoreMap, we track the exact junction box and upstream splice in under 5 minutes. Breakdown time dropped drastically.”
75% Faster Fault Recovery
MP
Pradeep
MCB
4.8
“We had years of route details scattered across paper diaries and rough notes. When senior staff were on leave, field work stalled. CoreMap completely digitized our routes and junction boxes. Now every technician sees the whole network on their mobile.”
100% Digital Route Records
SY
Yasar
Skywaves Cable
5.0
“Calculating optical loss across multi-stage splitters and couplers was always tricky. CoreMap calculates our optical budget automatically and shows live power levels at every junction box port. Zero signal guesswork.”
Accurate Optical dBm Budget
SS
Sumod
Star Digital
4.9
“Managing complex splice joints and keeping track of which PON port connects to each customer used to cause endless confusion on the field. With CoreMap, our splicers can simply tap any junction box on the digital map to see live fiber color codes, tube assignments, and customer drops. It completely streamlined our network maintenance.”
Streamlined Splice & Port Tracking
EA
Akhilesh
Eynet Vision
4.8
“Expanding into new wards used to require the supervisor to accompany technicians for line surveys. With CoreMap, new staff simply open the app, find available spare cores, and complete customer drops independently.”
3x Faster Field Expansions
MS
Suneer
Multistar
5.0
“We run both Cable TV and Gigabit Broadband on shared 24-core trunks. Keeping track of color coding and core allocations was a daily headache. CoreMap gives us a crystal-clear core matrix for every tube and junction box. Complete peace of mind.”
Unified Core Allocation
SB
Binoy
Satvision Cable
4.9
“Earlier, when a main fiber line was cut, our team spent 3 to 4 hours checking every single joint along the road. With CoreMap, we track the exact junction box and upstream splice in under 5 minutes. Breakdown time dropped drastically.”
75% Faster Fault Recovery
MP
Pradeep
MCB
4.8
“We had years of route details scattered across paper diaries and rough notes. When senior staff were on leave, field work stalled. CoreMap completely digitized our routes and junction boxes. Now every technician sees the whole network on their mobile.”
100% Digital Route Records
SY
Yasar
Skywaves Cable
5.0
“Calculating optical loss across multi-stage splitters and couplers was always tricky. CoreMap calculates our optical budget automatically and shows live power levels at every junction box port. Zero signal guesswork.”
Accurate Optical dBm Budget
SS
Sumod
Star Digital
4.9
“Managing complex splice joints and keeping track of which PON port connects to each customer used to cause endless confusion on the field. With CoreMap, our splicers can simply tap any junction box on the digital map to see live fiber color codes, tube assignments, and customer drops. It completely streamlined our network maintenance.”
Streamlined Splice & Port Tracking
EA
Akhilesh
Eynet Vision
4.8
“Expanding into new wards used to require the supervisor to accompany technicians for line surveys. With CoreMap, new staff simply open the app, find available spare cores, and complete customer drops independently.”
3x Faster Field Expansions
Data Ownership & Cloud Security
Your network, your data. Always secure, always in your control.
Zero vendor lock-in. Your fiber routes and subscriber mappings are your most valuable business asset. We back your network with live cloud sync, nightly multi-region snapshots, and instant one-click data export.
Zero Vendor Lock-In
Full Data Ownership & Easy Export
You maintain unconditional ownership of your network data. Export your entire database of routes, poles, junction boxes, and customer connections at any time with a single click.
📦
CoreMap_Network_Archive.zip
Complete Route & Splice Database
⚡ Full Routes • Poles • Customer DropsDownload Anytime ›
Daily Automated
Automated Cloud Backups & Version Recovery
Never worry about lost phones, hard drive crashes, or accidental staff deletions. Automated encrypted snapshots are captured every night across redundant cloud data centers.
Nightly Cloud Snapshot
03:00 AM IST✓ Today
✓ Yesterday
↺ 30-Day Rollback
99.9% Cloud Uptime
100% Cloud-Native with Live Field Sync
Access your entire network map anywhere on mobile, tablet, or desktop with active internet. Zero local server hardware to maintain. Field updates sync live across your entire team.
Real-Time Network PipelineSync Active
📱 Field App
⚡Cloud⚡
💻 Office Map
Role-Based Access Control
Role-Based Access & Staff Permissions
Empower your field teams and staff with precise role-based access controls. Linemen view only their designated routes, technicians manage joint splices, and administrators retain full governance over network data and sensitive configurations.
Role-Based Access MatrixRBAC Enabled
👑 Owner (Full)
🔧 Splicer (Edit)
📍 Lineman (View)
Binoy
Founder, CoreMap • Satvision Cable
Our Origin & Mission
Built by Operators, Engineered for the Field.
CoreMap was created by Binoy after 12+ years battling midnight fiber breakdowns, lost paper diaries, and lineman confusion. When an excavator cut our main line during monsoon rains and we spent 4 agonizing hours driving pole-to-pole, he engineered the practical, cloud-based tool local operators truly need.
Built for Electric Poles
High-contrast colors & one-handed controls for ladders.
Preserves Network Knowledge
Zero data loss when senior technicians leave.
< 5-Min Fault Tracing
Instant 12-fiber color code & cut point lookup.
100% Cloud-Based & Backed
Live field sync with one-click full data export.
TRANSPARENT PRICING
Simple Plans Built for Cable Operators
Zero setup fees, zero hidden charges. Annual plans tailored to your junction box and subscriber count.
Starter
Essential mapping for local operators starting out.
₹2,500/ year
Billed annually
₹5,000
Offer Price300
Junction Boxes
300
Subscribers
INCLUDED FEATURES
- Mobile GPS Pole & Box Mapping App
- Interactive Splice & Splitter Matrix
- Daily Cloud Backup & 1-Click Export
- Unlimited Staff & Tech Logins
- Real-Time Optical Budget & Fault Tracing
- Role-Based Staff Permissions
MOST POPULAR
Pro
Best for growing operators scaling network coverage.
₹3,000/ year
Billed annually
₹6,000
Offer Price500
Junction Boxes
500
Subscribers
INCLUDED FEATURES
- Mobile GPS Pole & Box Mapping App
- Interactive Splice & Splitter Matrix
- Daily Cloud Backup & 1-Click Export
- Unlimited Staff & Tech Logins
- Real-Time Optical Budget & Fault Tracing
- Role-Based Staff Permissions
Enterprise
Engineered for large multi-panchayat networks & MSOs.
₹5,000/ year
Billed annually
₹10,000
Offer Price1,000
Junction Boxes
1,000
Subscribers
INCLUDED FEATURES
- Mobile GPS Pole & Box Mapping App
- Interactive Splice & Splitter Matrix
- Daily Cloud Backup & 1-Click Export
- Unlimited Staff & Tech Logins
- Real-Time Optical Budget & Fault Tracing
- Role-Based Staff Permissions
Frequently Asked Questions
CoreMap helps cable operators digitize their physical network by mapping routes, junction boxes, couplers, and tracking fiber cores to ensure a reliable operational history.
Yes. CoreMap allows you to record the location, fiber-core count, color coding, connection status, ports, splices, couplers, and connected customers for every junction box.
Yes. CoreMap helps teams track individual fiber cores using standard IEC-style color coding within junction boxes.
Yes. Operators can trace fiber-core connections, internal joints, splice paths, ports, and fiber-to-fiber relationships inside every junction box.
Yes. You can track where each coupler is installed, its split ratio, its ports, and its connected routes.
Yes. You can connect customer records to the junction box, route, port, fiber core, coupler, and customer device serving them.
CoreMap helps identify the affected route, junction box, signal path, and customers more quickly during a cable breakdown or signal drop, reducing troubleshooting time.
Yes. CoreMap helps identify available fiber cores, open ports, available coupler points, and suitable connection paths before planning new installations.
Yes. CoreMap is built specifically to meet the network mapping needs of local cable operators, local ISPs, MSOs, and fiber teams.
